LC-4014 | Rainbow Finish - Black Tube

LC-4014 | Rainbow Finish, Black Tube -  Lifecare P4 Stethoscope

Bold Color with Clinical Precision

The Lifecare P4 LC-4014 stethoscope is where cutting-edge performance meets striking design. Featuring a sleek black tube and a vibrant rainbow-finished chestpiece, this model is perfect for professionals who want to combine functionality with flair.

Color: Rainbow Finish – Black Tube

• Model Code: LC-4014

• Color Profile: A bold and modern combination — the black tubing offers a clean, professional base, while the rainbow chestpiece adds a dynamic, eye-catching finish. Ideal for those who want to stand out while staying sharp.

• Accessories Included

• Delivery Fee Included

Product Features

For Dual Head Models (Chestpiece Selection): You may select either the diaphragm for high frequency response or the open bell for low frequency perception. To do so, hold the chestpiece stem in one hand and rotate the chestpiece at 180 degree with the other hand until it clicks into place. To determine the activated side, fit the headset's eartips in the ear, tap lightly each side (one at a time ), Transmitted sound will indicate which side is in operation.

For Pressure Sensitive Models: With the unique chestpiece design perception of both low and high frequency is available on the same side. The pressure sensitive diaphragm allows you to alter the frequency response by changing the contact pressure. Holding the chestpiece in place with light pressure will give you a low frequency response, whilst applying a firm fingertip pressure on the chestpiece gives a higher frequency response.

Binaural (Headset) Adjustments: The 15 degree angle of the binaural stem gives a complete and acoustically tight sealed fit. The eartips should be directed forward, towards the bridge of the nose to fit.

Adjustment of Binaural’s Spring Tension:

a. Reduce Tension - Using both hands, grip the binaural firmly with the fingers at the center of the "Y" in the tubing, thumbs at each side where rd tubing branches out. Flex the binaural gradually until desired tension is obtained.

b. Increase Tension - Cross binaural tube and grasp each by fingers. Pull binaural tube outwards, gently increasing the pressure, releasing and testing until satisfied.

Recommended For

• Physicians

• Nurses

• Medical Students

• Emergency Responders

• Pediatric and General Practitioners

Care and Maintenance:

a. Avoid contacting with extreme heat, cold, solvents or oils.
b. Avoid prolonging exposure to direct sunlight.
c. Clean the stethoscope between patients using either a 70% isopropyl alcohol solution.
d. Remove the eartips from binaural for through cleaning.
e. Check whether the eartips are firmly fixed on regular basis.
f. Do not submerge the unit in any liquid or steam sterilization.

Storage and Transport Conditions:

Ambient temperature -10°C to +40°C

Relative humid: y 95% or below, non - condensing

Atmospheric pressure 700 - 1060 hPa

Refer User Manual Page for:

Warranty and Service Program
Rapid ConversionTM Diaphragm / Non-Chill Ring
Other Matters
